PowerShare PS604D adaptable power amplifier
Power Amplifiers

PowerShare PS604D adaptable power amplifier

Put the power where you need it. PowerShare amplifiers deliver outstanding audio performance and reliability with patented technologies inherited from the field-proven Bose Professional PowerMatch line — now with added flexibility. Using innovative PowerShare technology, the amp shares power across all output channels and delivers 600 watts for installed applications. This means you can distribute the total 600 watts asymmetrically across all outputs or use any individual output to deliver full power. And with support for both low- and high-impedance loads up to 100V, it’s easy to adapt PowerShare amplifiers to a wide range of applications. ControlSpace Designer software allows for Ethernet-based configuration and quick setup of external control options. With onboard Dante

audio networking, you have the flexibility to place PowerShare amplifiers away from source locations and closer to loudspeakers. This unique set of features and technologies makes PowerShare one of the most versatile, high-performance amplifiers available today.

Order Codes · 5

See all →
Request a Full System Quote
  • Authorized productFull manufacturer warranty
  • Ships from A5 ITCrystal Lake, Illinois
  • Design supportSpecify the whole system

Features

  • PowerShare technology:Distribute the total 600 watts asymmetrically across all outputs using patented PowerShare technology, which allows each output to deliver full power. Instead of selecting amplifier power based on the needs of the largest zone, you now have the freedom to use total amplifier power in any application. This enables more flexibility during the initial design, or later on-site when making unplanned changes that take advantage of surplus power.

  • Load-independent outputs:Configure any channel for low-impedance (4-8 Ω) or high-impedance (70/100V) applications without bridging or using jumpers.

  • Integrated Dante audio networking:Support four audio input channels from a Dante network and mix onboard analog inputs with digital Dante inputs as selected in ControlSpace Designer software.

  • Dual Feedback Loop system:Improve performance and reliability. The Dual Feedback Loop system, inherited from the field-proven Bose Professional PowerMatch amplifier line, allows for continuous monitoring and control of both the current and voltage delivered to each output load. This combination provides improved linearity and lower distortion while protecting loudspeakers.

  • ControlSpace networking:Configure using ControlSpace Designer software for inclusion into larger networked audio systems where end-user controllers and scheduling events can control amplifier parameters.

  • Integrated Loudspeaker Processing:Adjust various parameters using ControlSpace Designer software: nine-band PEQs, matrix mixing, crossover, limiters, delay, mute/output polarity, and more.

  • Auto-standby:Save power — PowerShare amplifiers can be configured to automatically enter standby mode when the audio signal falls below a set threshold, then wake when audio returns.

Applications

Designed for a wide range of applications, including:

  • Performing arts venues
  • Places of worship
  • Conference centers
  • Retail stores
  • Restaurants and bars
  • Hospitality venues

Specifications

50 specifications

AMPLIFICATION

Channel Separation (Crosstalk)
> 85 dB at 1 kHz, > 65 dB at 20 kHz
Dynamic Range
100 dB at rated power, A-weighted
Gain, High-Impedance
35 dB, 70V mode / 38 dB, 100V mode
Gain, Low-Impedance
32 dB
Maximum Peak Power, Symmetrical
300 W
Maximum Peak Power, Asymmetrical
1200 W
Rated Power, Asymmetrical
600 W
SNR
100 dB (at rated power, A-weighted)
Frequency Response
20 Hz – 20 kHz (±0.5 dB) at 1 W
Number of Channels
4
Rated Power, Symmetrical
150 W
THD+N
< 0.04% at 1 kHz, 4–8 Ω, 70V/100V

AUDIO INPUTS, ANALOG

Input Channels
4 balanced, line
Connectors
(1) 12-pin Euroblock
Input Impedance
20 kΩ
Maximum Input Level
20 dBu at 12 dBu sensitivity
Sensitivity
4 dBu low, 12 dBu high

AUDIO INPUTS/OUTPUTS, DIGITAL

Channels
4 Dante in
Connectors
(2) RJ-45 Dante in/thru
Type
12-pin Euroblock

AUDIO OUTPUTS, ANALOG

Channels
4
Connectors
(1) 8-pin inverted Euroblock

COMPLIANCE

EMC
This product meets all EN55103-2 immunity requirements for E2 electromagnetic environment.

ELECTRICAL

Current Draw, Idle
0.1 A at 120 VAC, 60 Hz / 0.06 A at 230 VAC, 50 Hz
Current Draw, Inrush
8.0 A at 120 VAC, 60 Hz / 14.1 A at 230 VAC, 50 Hz
Mains Connector
IEC C14 inlet
Mains Voltage
100–240 VAC (±10%), 50/60 Hz
Protections
High temperature, output short circuit, extra high frequency, excessively low/high AC line voltage
AC Power Consumption
14 W standby, 700 W maximum

GENERAL

Software Applications
ControlSpace Designer 5.4 or later (Windows)
Computer Interface Connection
RJ-45 (Ethernet, 100 Mbps)

INDICATORS AND CONTROLS

Controls, Front Panel
(1) power button
Controls, Rear Panel
Output attenuators, mute contact
LED Status Indicators
(1) power/status LED, (4) input signal LEDs, (4) output limit LEDs

INTEGRATED DSP

Delay
50 ms, Outputs 3–4 only
Equalization
Input EQ: 9-band parametric EQ (±18 dB), notch, shelving, high-pass, low-pass / band-pass crossover / loudspeaker EQ: 9-band parametric EQ (±18 dB), notch, shelving
Crossover Types
Butterworth, Bessel, or Linkwitz-Riley, up to 48 dB/octave
A/D and D/A Converters
48 kHz / 24-bit
Audio Latency
< 1 ms, analog input to analog output
DSP-Enabled
Yes
Limiters
Peak voltage, RMS voltage
Presets
Bose Professional loudspeaker presets
Processing Functions
Input EQ, loudspeaker EQ, peak voltage limiter, RMS voltage limiter, delay, band-pass, matrix mixer, mute/output polarity inversion

PHYSICAL

Colors
Black
Cooling System
Microprocessor controlled, variable speed fans, left to right air flow
Suspension/Mounting
Rack-mounting
Product Dimensions (H×W×D)
1.7 in × 19.0 in × 16.3 in (44 mm × 483 mm × 414 mm)
Net Weight
14.1 lb (6.4 kg)
Rack Spaces
1
Shipping Weight
17.2 lb (7.8 kg)

Order Codes

Order CodeDescriptionAvailability
813403-1310120 V, USGet Price
813403-2310230 V, EUGet Price
813403-5310230 V, AUGet Price
813403-4310230 V, UKGet Price
813403-3310100 V, JPGet Price

In the Box

  • 5 years
  • (1) 2-pin Euroblock connector
  • (1) 8-pin Euroblock connector
  • (1) 12-pin Euroblock connector
  • (1) installation guide
  • (1) PowerShare PS604D
  • (1) IEC power cord
