Loudspeakers
FreeSpace 360P Series II
Full-range environmental loudspeaker designed to blend with landscaping for in-ground or above-ground applications, such as shopping malls, outdoor restaurants, resorts and theme parks. Features 360° horizontal coverage and frequency range down to 60 Hz. For indoor and outdoor applications.
Features
Applications
Designed for a wide range of applications, including:
Specifications
PHYSICAL
- Ingress Protection
- IP55
- Suspension/Mounting
- 3 × #10 (M4) holes in base, 3 × #10 (M4) screws required
- Product Dimensions (H×W×D)
- 368 mm × 379 mm (14.5 in × 14.9 in), loudspeaker diameter × height
- Net Weight
- 14.5 lb (6.6 kg)
- Shipping Weight
- 14.9 lb (6.8 kg)
PERFORMANCE
- Frequency Range (-10 dB)
- 60 Hz – 15,000 Hz
- Coverage, Horizontal
- 360°
- Calculated Maximum SPL @ 1 m
- 107 dB
- Nominal Impedance
- 8Ω (transformer bypassed)
- Power Handling, long-term continuous
- 70/100V: 80 W / 8Ω: 30 W
- Power Handling, Peak
- 70/100V: 320 W / 8Ω: 120 W
- Recommended Signal Processing
- No Bose Professional EQ required. For best performance, Bose Professional EQ presets available.
- Sensitivity (SPL/1 W at 1 m)
- 87 dB
- Transformer Taps, 100V
- 10, 20, 40, 80 W, bypass
- Transformer Taps, 70V
- 10 W, 20 W, 40 W, 80 W, bypass
- Coverage, Vertical
- 50°
TRANSDUCERS
- Driver Protection
- Recommended high-pass filter 60 Hz with minimum 24-dB/octave filter, Presets available
- Low-Frequency
- 1 × Bose Professional 4.5 in (114 mm) environmental driver
In the Box
